![Tp-Link T1700G-28TQ V2 [455/772] Follow these steps to configure option 82](/views2/1472751/page455/bg1c7.png)
Configuration Guide 430
Configuring DHCP Relay DHCP Relay Configuration
2.2 Using the CLI
2.2.1 Enabling DHCP Relay
Follow these steps to enable DHCP Relay:
Step 1 configure
Enter global configuration mode.
Step 2 service dhcp relay
Enable DHCP Relay.
Step 3 end
Return to Privileged EXEC Mode.
Step 4 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to enable DHCP Relay:
Switch#configure
Switch(config)#service dhcp relay
Switch(config)#show ip dhcp relay
DHCP relay is enabled.
......
Switch(config)#end
Switch#copy running-config startup-config
2.2.2 Configuring Option 82
Follow these steps to configure Option 82:
Step 1 configure
Enter global configuration mode.
Step 2 ip dhcp relay information
Enable the Option 82 feature.
