![Tp-Link T1700G-28TQ V2 [333/772] Enabling igmp snooping globally](/views2/1472751/page333/bg14d.png)
Configuration Guide 308
Configuring Layer 2 Multicast IGMP Snooping Configurations
2) Click Create.
Viewing IGMP Static Multicast Groups
You can search IGMP static multicast entries by using Multicast IP, VLAN ID or Forward
Port as the Search Option.
Static Multicast IP Table displays details of all IGMP static multicast groups.
2.2 Using the CLI
2.2.1 Enabling IGMP Snooping Globally
Step 1 configure
Enter global configuration mode.
Step 2 ip igmp snooping
Enable IGMP Snooping Globally.
Step 3 end
Return to privileged EXEC mode.
Step 4 show ip igmp snooping
Show the basic IGMP snooping configuration.
Step 5 copy running-config startup-config
Save the settings in the configuration file.
2.2.2 Enabling IGMP Snooping on the Port
Step 1 configure
Enter global configuration mode.
Step 2 interface { fastEthernet
por
t
| range fastEthernet
port-lis
t
| gigabitEthernet
por
t
| range
gigabitEthernet
port-lis
t
| ten-gigabitE
thernet
port |
r
ange ten-gigabitEthe
rnet
port-list }
Enter interface configuration mode.
Step 3 ip igmp snooping
Enable IGMP Snooping on the specified port.
Step 4 end
Return to privileged EXEC mode.
Step 5 show ip igmp snooping
Show the basic IGMP snooping configuration.
