![Tp-Link T1700G-28TQ V2 [334/772] Configuring report message suppression](/views2/1472751/page334/bg14e.png)
Configuration Guide 309
Configuring Layer 2 Multicast IGMP Snooping Configurations
Step 6 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to enable IGMP Snooping globally and enable IGMP
Snooping on port 1/0/3:
Switch#configure
Switch(config)#ip igmp snooping
Switch(config)#interface gigabitEthernet 1/0/3
Switch(config-if)#ip igmp snooping
Switch(config-if)#show ip igmp snooping
IGMP Snooping :Enable
Unknown Multicast :Pass
Last Query Times :2
Last Query Interval :1
Global Member Age Time :260
Global Router Age Time :300
Global Report Suppression :Disable
Global Authentication Accounting: Disable
Enable Port:Gi1/0/3
Enable VLAN:
Switch(config-if)#end
Switch#copy running-config startup-config
2.2.3 Configuring IGMP Snooping Parameters Globally
Configuring Report Message Suppression
Step 1 configure
Enter global configuration mode.
Step 2 ip igmp snooping report-suppression
Enable Report Message Suppression globally. If this function is enabled, the switch will only
forward the first IGMP report message to Layer 3 devices and suppress subsequent IGMP
report messages from the same multicast group during one query interval, which reduces the
number of IGMP packets.
