Configuration Guide 514
Configuring ACL ACL Configuration
Figure 2-3 Creating an ACL
Follow these steps to create an ACL:
1) In the ACL Create section, assign a name to the ACL
.
ACL ID Enter a number to identify the ACL
2) Click Apply to make the settings effective.
Note:
TThe supported ACL type and ID range varies on different switch models. Please refer to the on-
screen information.
2.1.4 Configuring ACL Rules
Add rules to the ACL. For details, refer to MAC ACL Rule,Standard-IP ACL Rule, Extend-IP
ACL Rule and IPv6
Configuring the MAC ACL Rule
Choose the menu ACL > ACL Config > MAC ACL to load the following page.
Figure 2-4 Creating the MAC ACL
