![Tp-Link T1700G-28TQ V2 [552/772] You can define the rules based on source or destination ip address source or destination mac address protocol type port number and others](/views2/1472751/page552/bg228.png)
Configuring ACL ACL Configuration
Configuration Guide
527
Step 5 holiday
name
start-date
start-date
end-date
end-date
In Holiday mode, specify the start and end date of the holiday time.
name
：
Assign a name to the holiday using 1-16 characters.
start-date
：
Specify the start date in MM/DD format, for example 05/01.
end-date
：
Specify the end date in MM/DD format, for example 05/03
Step 6 show time-range
(Optional) Display all time-range configurations.
show holiday
(Optional) Display all defined holiday times.
Step 7 end
Return to privileged EXEC mode.
Step 8 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to configure time-range:
Switch#config
Switch(config)#time-range work_time
Switch(config-time-range)#periodic week-date 1-5 time-slice1 08:30-18:00
Switch(config-time-range)#exit
Switch(config)#show time-range
Time-range entry: work_time(inactive)
periodic time-slice 08:30-18:00
periodic week-day 1,2,3,4,5
Switch(config)#end
Switch#copy running-config startup-config
2.2.2 Configuring ACL
Follow the steps to create different types of ACL and configure the ACL rules.
You can define the rules based on source or destination IP address, source or destination
MAC address, protocol type, port number and others.
MAC ACL
Step 1 config
Enter global configuration mode.
