![Tp-Link T1700G-28TQ V2 [337/772] Last query times 2](/views2/1472751/page337/bg151.png)
Configuring Layer 2 Multicast IGMP Snooping Configurations
Configuration Guide
312
2.2.4 Configuring IGMP Snooping Parameters on the Port
Configuring Router Port Time and Member Port Time
Step 1 configure
Enter global configuration mode.
Step 2 ip igmp snooping rtime
rtime
ip igmp snooping mtime
mtime
rtime
is the aging time of router ports, ranging from 60 to 600 seconds.
mtime
is the aging time of member ports, ranging from 60 to 600 seconds.
Step 3 end
Return to privileged EXEC mode.
Step 4 show ip igmp snooping
Show the basic IGMP snooping configuration.
Step 5 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to configure the global router port time and member
port time as 200 seconds:
Switch#configure
Switch(config)#ip igmp snooping
Switch(config)#ip igmp snooping rtime 200
Switch(config)#ip igmp snooping mtime 200
Switch(config)#show ip igmp snooping
IGMP Snooping :Enable
Unknown Multicast :Pass
Last Query Times :2
Last Query Interval :1
Global Member Age Time :200
Global Router Age Time :200
Global Report Suppression :Disable
Global Authentication Accounting:Disable
Enable Port:
Enable VLAN:
