![Tp-Link T1700G-28TQ V2 Руководство пользователя онлайн [336/772] 394694](/views2/1472751/page336/bg150.png)
Configuration Guide 311
Configuring Layer 2 Multicast IGMP Snooping Configurations
Step 3 end
Return to privileged EXEC mode.
Step 4 show ip igmp snooping
Show the basic IGMP snooping configuration.
Step 5 copy running-config startup-config
Save the settings in the configuration file.
For switches that support MLD Snooping, IGMP Snooping and MLD Snooping share the
setting of Unknown Multicast, so you have to enable MLD Snooping globally at the same
time.
The following example shows how to configure the switch to discard unknown multicast
data:
Switch#configure
Switch(config)#ip igmp snooping
Switch(config)#ipv6 mld snooping
Switch(config)#ip igmp snooping drop-unknown
Switch(config)#show ip igmp snooping
IGMP Snooping :Enable
Unknown Multicast :Discard
Last Query Times :2
Last Query Interval :1
Global Member Age Time :260
Global Router Age Time :300
Global Report Suppression :Disable
Global Authentication Accounting:Disable
Enable Port:
Enable VLAN:
Switch(config-if)#end
Switch#copy running-config startup-config
