Configuring SNMP & RMON SNMP Configurations
Configuration Guide
699
2
SNMP Configurations
To complete the SNMP configuration, choose an SNMP version according to network
requirements and supportability of the NMS software, and then follow these steps:
Choose SNMPv3
1) Enable SNMP.
2) Create an SNMP view for managed objects.
3) Create an SNMP group, and specify the access rights.
4) Create SNMP users, and configure the authentication mode, privacy mode and
corresponding passwords.
Choose SNMPv1 or SNMPv2c
1) Enable SNMP.
2) Create an SNMP view for managed objects.
3) Direct configuration: Create a community, specify the accessible view and the
corresponding access rights.
Indirect configuration: See steps 3) and 4) of
Choose SNMPv3
. In this situation, the user
name functions as the community name, and the Read/Write View is the same for the
user and the group.
