![Tp-Link T1700G-28TQ V2 [366/772] Switch config if end](/views2/1472751/page366/bg16e.png)
Configuring Layer 2 Multicast Configuring MLD Snooping
Configuration Guide
341
Step 3 ipv6 mld snooping
Enable MLD Snooping on the specified port.
Step 4 show ipv6 mld snooping
Show the basic MLD snooping configuration.
Step 5 end
Return to privileged EXEC mode.
Step 6 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to enable MLD Snooping globally and enable MLD
Snooping Switch#configure
Switch(config)#ipv6 mld snooping
Switch(config)#interface gigabitEthernet 1/0/3
Switch(config-if)#ipv6 mld snooping
Switch(config-if)#show ipv6 mld snooping
MLD Snooping :Enable
Unknown Multicast :Pass
Last Query Times :2
Last Query Interval :1
Global Member Age Time :260
Global Router Age Time :300
Global Report Suppression :Disable
Enable Port:Gi1/0/3
Enable VLAN:
Switch(config-if)#end
Switch#copy running-config startup-config
3.2.3 Configuring MLD Snooping Parameters Globally
Configuring Report Message Suppression
Step 1 configure
Enter global configuration mode.
