Configuration Guide 338
Configuring Layer 2 Multicast Configuring MLD Snooping
Max Group Enter the number of multicast groups the port can join. The valid values are from
0 to 1000.
Overflow Action Select the action towards the new multicast group when the number of multicast
groups the port joined exceeds max group.
Drop: Drop all subsequent membership report messages, and the port will not join
any new multicast groups.
Replace: Replace the existing multicast group owning the lowest multicast MAC
address with the new multicast group.
2) Click Apply.
3.1.8 Viewing MLD Statistics on Each Port
Choose the menu Multicast > MLD Snooping > Packet Statistic to load the following
page.
Figure 3-9 View MLD Statistics on the Port
Configuring Auto Refresh
Follow these steps to configure auto refresh.
