Configuration Guide 520

Configuring ACL ACL Configuration

Figure 2-8 ACL Information

2.1.5 Configuring Policy

Policy allows you to further process the matched packets through operations such as

mirroring, rate-limiting, redirecting, or changing priority.

To configure the policy, follow these steps:

1) Create a policy.

2) Configure the action of the policy

Creating a Policy

Choose th menu ACL > Policy Config > Policy Create to load the following page.

Figure 2-9 Creating a Policy

Follow these steps to create a policy:

Enter a Policy Name, and click Apply.

Policy Name Enter a Policy Name between 1 and 16 characters.

Configuring the Action of the Policy

Apply an ACL to the Policy and specify the action to be taken for the matched packets.

Choose the menu ACL > Policy Config > Action Create to load the following page.
