![Tp-Link T1700G-28TQ V2 [551/772] Using the cli](/views2/1472751/page551/bg227.png)
Configuration Guide 526
Configuring ACL ACL Configuration
2.2 Using the CLI
2.2.1 Configuring Time Range
Some services or features that use ACL need to be limited to a specified time period. In this
case, you can configure time-range for the ACL.
Step 1 configure
Enter global configuration mode.
Step 2 time-range
name
Add a time-range to make a rule effective only during a specified time period.
name
：
Assign a name to the time-range using 1-16 characters.
Step 3 absolute start
start-date
end
end-date
(Optional) Configure time-range in Absolute mode. In this mode, the rule takes effect only during a
specified period of time.
start-date:
Specify the start date in MM/DD/YYYY format. The default is 01/01/2000.
end-date:
Specify the start date in MM/DD/YYYY format. The default is 01/01/2000
periodic
[
week-date
week-day
] [
time-slice1
time-slice
] [
time-slice2
time-slice
]
[
time-slice3
time-slice
] [
time-slice4
time-slice
]
(Optional) Configure time-range in Week mode. In this mode, the rule takes effect only on certain days
each week.
week-day
：
Specify the cycle time range. You can enter 1-3,6 or descriptions such as daily, off-day or
working-day. 1-3, 6 indicates Monday, Tuesday,Wednesday and Saturday; daily indicates every day; off-
day indicates Saturday and Sunday, and working-day indicates Monday to Friday.
By default, Week mode is disabled.
time-slice
：
Add a time-slice in HH:MM-HH:MM format. You can add a maximum of four time-slices to
each time-range.
holiday
(Optional) Configure time-range in Holiday mode. In this mode, the ACL rule is effective only during
specified holiday times.
Step 4 exit
Return to global configuration mode.
