Configuration Guide 86
Configuring Stack Stack Configuration
Step 1 configure
Enter global configuration mode.
Step 2 switch stack-port interface ten-gigabitEthernet
port
Enable the specified port as stack port.
port:
Specify the port to be configured.
Note: Demonstrated with T1700G-28TQ, port 1/0/25 and 1/0/26 are in Stack Port
Group 0 and 1/0/27 and 1/0/28 are in Stack Port Group 1. Stack feature can only be
enabled in one group at a time.
Step 3 show switch stack-ports
Displays the information of all the stack ports in the stack.
Step 4 end
Return to privileged EXEC mode.
Step 5 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to configure port 1/0/25 and 4/0/25 as stack ports:
Switch#configure
Switch(config)#switch stack-port interface ten-gigabitEthernet 1/0/25
Enabling/disabling a stack port may cause undesired stack changes. Continue?[Yes/No]Y
Switch(config)#switch stack-port interface ten-gigabitEthernet 4/0/25
Enabling/disabling a stack port may cause undesired stack changes. Continue?[Yes/No]Y
Switch(config)#show switch stack-ports
Stack Port Group Status
---------- ----- -------
1/0/25 0 OK
1/0/26 0 Ethernet
1/0/27 1 Ethernet
1/0/28 1 Ethernet
4/0/25 0 OK
4/0/26 0 Ethernet
4/0/27 1 Ethernet
