![Tp-Link T1700G-28TQ V2 [344/772] Member time 400](/views2/1472751/page344/bg158.png)
Configuring Layer 2 Multicast IGMP Snooping Configurations
Configuration Guide
319
2.2.7 Configuring IGMP Snooping Parameters in the Multicast VLAN
Configuring Router Port Time and Member Port Time
Step 1 configure
Enter global configuration mode.
Step 2 ip igmp snooping multi-vlan-config [
vlan-id
]
[rtime
router-time
| mtime
member-time
]
vlan-id
specifies the VLAN to be created or to be configured.
router-time
is the aging time of the router ports in the multicast VLAN, ranging from 60 to 600
seconds.
member-time
is the aging time of the member ports in the multicast VLAN, ranging from 60 to
600 seconds.
Step 3 show ip igmp snooping multi-vlan
Show the IGMP snooping configuration in the multicast VLAN.
Step 4 end
Return to privileged EXEC mode.
Step 4 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to configure VLAN 5 as the multicast VLAN, set the
router port time as 500 seconds and the member port time as 400 seconds:
Switch#configure
Switch(config)#ip igmp snooping
Switch(config)#ip igmp snooping multi-vlan-config 5 rtime 500
Switch(config)#ip igmp snooping multi-vlan-config 5 mtime 400
Switch(config)#show ip igmp snooping multi-vlan
Multicast Vlan:Enable
Vlan Id: 5
Router Time:500
Member Time:400
Static Router Port:None
Dynamic Router Port:None
Switch(config)#end
Switch#copy running-config startup-config
