![Tp-Link T1700G-28TQ V2 [109/772] Using the cli](/views2/1472751/page109/bg6d.png)
Configuration Guide 84
Configuring Stack Stack Configuration
2.2 Using the CLI
2.2.1 Configuring the Stack Member’s Priority
Follow these steps to configure the priority of the specified stack member:
Step 1 configure
Enter global configuration mode.
Step 2 switch
unit-id
priority
priority
Configure the priority of the specified stack member.
unit-id:
Specify the stack member to be configured.
priority:
Specify the member’s new priority. A higher priority value for a stack member
increases its likelihood of being elected the stack master. The new priority value
takes effect immediately but does not affect the current stack master. The new
priority helps determine which stack member is elected as the new stack master
when the current stack master or the stack resets.
Step 3 show switch [
unit-id
]
Displays the information of all the stack members or of the specified stack member.
Step 4 end
Return to privileged EXEC mode.
Step 6 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to configure stack unit1’s priority as 15:
Switch#configure
Switch(config)#switch 1 priority 15
Switch(config)#show switch 1
Stack Topo : Solo
Switch/Stack Mac Address : 50:C7:BF:07:5F:0E
Switch# New ID Role Mac Address Priority Version Switch Type State
------- --------- ------ ----------------- -------- ------- ---------------- -----
* 1 4 Master 50:C7:BF:07:5F:0E 15 2.0.0 T1700G-28TQRev2 Ready
Switch(config)#end
Switch#copy running-config startup-config
