Configuring 802.1Q VLAN Configuration Example

Configuration Guide

183

Configuration Example

3.1 Network Requirements



Offices of both Department A and Department B in the company are located in different

places, and computers in different offices are connected to different switches.



It is required that computers can communicate with each other in the same department

but not with computers in the other department.

3.2 Configuration Scheme



Divide computers in Department A and Department B into two VLANs respectively so

that computers can communicate with each other in the same department but not with

computers in the other department.



Terminal devices like computers usually do not support VLAN tags. Configure the

switch ports connected to the computers as Untagged. Then add the ports to the

corresponding VLANs.



The intermediate link between two switches carries traffic from two VLANs

simultaneously. Configure the ports on both ends of the intermediate link as Tagged,

and add the ports to both VLANs.
