Configuring Layer 2 Multicast Appendix: Default Parameters
Configuration Guide
391
6.2 Default Parameters for MLD Snooping
Table 6-2 Default Parameters of MLD Snooping
Function Parameter Default Setting
Global Settings of IGMP
Snooping
MLD Snooping Disabled
Unknown Multicast Forward
Report Message Suppression Disabled
Router Port Time 300 seconds
Member Port Time 260 seconds
Last Listener Query Interval 1 second
Last Listener Query Count 2
MLD Snooping on the Port
MLD Snooping Disabled
Fast Leave Disabled
MLD Snooping in the VLAN
Enable or Not Disabled
Router Port Time 0, use global settings.
Member Port Time 0, use global settings.
Multicast VLAN
Multicast VLAN None
Router Port Time 0, use global settings.
Member Port Time 0, use global settings.
IGMP Snooping Querier
Enable or Not Disabled
Query Interval 60 seconds
Max Response Time 10 seconds
General Query Source IP FE80::02FF:FFFF:FE00:0001
