Configuration Guide 93

Configuring Stack Configuration Example

2/0/25 0 OK 3

2/0/26 0 OK 1

2/0/27 1 Ethernet None

2/0/28 1 Ethernet None

3/0/25 0 OK 1

3/0/26 0 OK 2

3/0/27 1 Ethernet None

3/0/28 1 Ethernet None

9) Save the settings.

Switch(config)#end

Switch#copy running-config startup-config

3.2 Replacing a Stack Member with a New Unit

3.2.1 Network Requirements

In the ring stack established in

3.1 Ring Stack Application

, if one stack member (for

example, switch C) fails, a new switch is required to replace the failure one. Ensure that the

new unit has the same global and interface configurations as the former one.

3.2.2 Configuration Scheme

You can use the provision feature to complete the unit replacement.

The provisioned configuration is automatically created when a switch is added to the stack.

After a switch member is removed from the stack, all its configuration still remains in the

stack’s running configuration as a provisioned configuration.

If a stack member fails and you replace it with an identical model (and pre-configure

the new switch’s unit ID the same as the failed one’s), the stack applies the provisioned

configuration to the new member. That is, the new one and the old one have exactly the

same global settings and interface settings.

3.2.3 Using the GUI

1) Power on the new factory-setting T1700G-28TQ. Configure its unit ID the same as the

failed model’s , and enable 1/0/25 and 1/0/26 as stack ports.
