![Tp-Link T1700G-28TQ V2 [329/772] Viewing igmp statistics on each port](/views2/1472751/page329/bg149.png)
Configuring Layer 2 Multicast IGMP Snooping Configurations
Configuration Guide
304
Profile ID Enter the profile ID you create to bind the profile to the port. One port can only be
bound to one profile.
ClearBinding Click to clear the binding between the profile and the port.
2) Click Apply.
Configuring Max Groups a Port Can Join
Follow these steps to configure the maximum groups a port can join and overflow action.
1) Select a port to configure its Max Group and Overflow Action.
Select Select the port to be configured.
Max Group Enter the number of multicast groups the port can join. The valid values are from
0 to 1000.
Overflow Action Select the action towards the new multicast group when the number of multicast
groups the port joined exceeds max group.
Drop: Drop all subsequent membership report messages, and the port will not join
any new multicast groups.
Replace: Replace the existing multicast group owning the lowest multicast MAC
address with the new multicast group.
2) Click Apply.
2.1.8 Viewing IGMP Statistics on Each Port
Choose the menu Multicast > IGMP Snooping > Packet Statistic to load the following
page.
