![Tp-Link T1700G-28TQ V2 [188/772] Aging time is 500 sec](/views2/1472751/page188/bgbc.png)
Managing MAC Address Table Address Configurations
Configuration Guide
163
Switch#copy running-config startup-config
2.2.2 Modifying the Aging Time of Dynamic Address Entries
Follow these steps to modify the aging time of dynamic address entries:
Step 1 configure
Enter global configuration mode.
Step 2 mac address-table aging-time
aging-time
Set your desired length of address aging time for dynamic address entries.
aging-time:
Set the length of time that a dynamic entry remains in the MAC address table after
the entry is used or updated. The valid values are from10 to 630. When 0 is entered, the Auto
Aging function is disabled. The default value is 300 and we recommend you keep the default
value if you are unsure about settings in your case.
Step 3 end
Return to privileged EXEC mode.
Step 4 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to modify the aging time to 500 seconds. A dynamic
entry remains in the MAC address table for 500 seconds after the entry is used or updated.
Switch#configure
Switch(config)# mac address-table aging-time 500
Switch(config)#show mac address-table aging-time
Aging time is 500 sec.
Switch(config)#end
Switch#copy running-config startup-config
2.2.3 Adding MAC Filtering Address Entries
Follow these steps to add MAC filtering address entries:
Step 1 configure
Enter global configuration mode.
