Configuring ACL ACL Configuration
Configuration Guide
519
IPv6 Source IP When selected, enter the source IP address with a mask.
S-IP Enter the source IPv6 address to be matched. All types of IPv6 address will
be checked. You may enter a complete 128-bit IPv6 address but only the
first 64 bits will be valid.
Mask The mask is required if the source IPv6 address is entered. Enter the mask in
complete format (for example, ffff:ffff:0000:ffff).
The IP address mask specifies which bits in the source IPv6 address to
match the rule. A value of 1 in the mask indicates that the corresponding bit
in the address will be matched.
IPv6 Destination IP When selected, enter the destination IPv6 address with a mask.
D-IP Enter the destination IPv6 address to be matched. All types of IPv6 address
will be checked. You may enter a complete 128-bit IPv6 address but only the
first 64 bits will be valid.
Mask The mask is required if the destination IPv6 address is entered. Enter the
complete mask (for example, ffff:ffff:0000:ffff).
The IP address mask specifies which bits in the source IP address to match
the rule. A value of 1 in the mask indicates that the corresponding bit in the
address will be matched.
S-Port / D-Port Enter the TCP/UDP source and destination port.
3) (Optional) Select a time-range from the drop-down list.
Time-Range Select a time-range during which the rule will take effect. The default value is
No Limit, which means the rule is always in effect..
View the Rule Table
The rules in an ACL are listed in ascending order of configuration time, regardless of their
rule IDs.
By default, a rule configured earlier is listed before a rule configured later.
The switch matches a received packet with the rules in order. When a packet matches a
rule, the device stops the match process and performs the action defined in the rule.
In the ACL rule table, you can view all the ACLs and their rules.
You can also delete an ACL or an ACL rule, or change the matching order if needed.
Choose the menu ACL > ACL Config > ACL Summary to load the following page.
