![Tp-Link T1700G-28TQ V2 [163/772] Switch configure](/views2/1472751/page163/bga3.png)
Configuration Guide 138
Configuring LAG LAG Configuration
The following example shows how to add ports1/0/5-8 to LAG 2 and set the mode as static
LAG:
Switch#configure
Switch(config)#interface range gigabitEthernet 1/0/5-8
Switch(config-if-range)#channel-group 2 mode on
Switch(config-if-range)#show etherchannel 2 summary
Flags: D - down P - bundled in port-channel U - in use
I - stand-alone H - hot-standby(LACP only) s - suspended
R - layer3 S - layer2 f - failed to allocate aggregator
u - unsuitable for bundling w - waiting to be aggregated d - default port
Group Port-channel Protocol Ports
----- --------- ------- -------------------------------
2 Po2(S) - Gi1/0/5(D) Gi1/0/6(D) Gi1/0/7(D) Gi1/0/8(D)
Switch(config-if-range)#end
Switch#copy running-config startup-config
Configuring LACP
Follow these steps to configure LACP:
Step 1 configure
Enter global configuration mode.
Step 2 lacp system-priority
pri
Specify the system priority for the switch.
To keep active ports consistent at both ends, you can set the priority of one device to be
higher than that of the other device. The device with higher priority will determine its active
ports, and the other device can select its active ports according to the selection result of
the device with higher priority. If the two ends have the same system priority value, the end
with a smaller MAC address has the higher priority.
pri:
System priority. The valid values are from 0 to 65535, and the default value is 32768. A smaller
value means a higher device priority.
Step 3 interface { fastEthernet
port |
range fastEthernet
port-list |
gigabitEtherne
t port |
range
gigabitEtherne
t port-list
| ten-gigabitEthernet
port
| range ten-gigabitEthernet
port-list
}
Enter interface configuration mode.
