![Tp-Link T1700G-28TQ V2 [112/772] Switch stack mac address 50 c7 bf 07 5f 0e](/views2/1472751/page112/bg70.png)
Configuration Guide 87
Configuring Stack Stack Configuration
4/0/28 1 Ethernet
Switch(config)#end
Switch#copy running-config startup-config
2.2.4 Configuring the Provisioned Stack Member
Follow these steps to create a provisioned stack member:
Step 1 configure
Enter global configuration mode.
Step 2 switch
unit-id
provision
type
Configure the provisioned stack member with the unit ID and the device type.
unit-id:
Specify a stack member unit ID that is not already used in the stack. The
range is from 1 to 6.
type:
Enter the model number of the supported switch. You can enter ? to view the
supported models.
Step 3 show switch
Displays the information of all the stack members, including the provision member.
Step 4 end
Return to privileged EXEC mode.
Step 6 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to create a provisioned stack member as unit 2 and
T1700G-28TQRev2:
Switch#configure
Switch(config)#switch
2
provision T1700G-28TQRev2
Switch(config)#show switch
Stack Topo : Solo
Switch/Stack Mac Address : 50:C7:BF:07:5F:0E
Switch# New ID Role Mac Address Priority Version Switch Type State
------- --------- ------ ----------------- -------- ------- ---------------- -----
* 1 AUTO Master 00:0A:EB:13:12:3E 5 2.0.0 T1700G-28TQRev2 Ready
2 --- --- --- --- --- T1700G-28TQRev2 Provisioned
4 4 Member 50:C7:BF:07:5F:0E 15 2.0.0 T1700G-28TQRev2 Ready
