Configuring Layer 2 Multicast Viewing Multicast Snooping Configurations
Configuration Guide
358
4
Viewing Multicast Snooping Configurations
4.1 Using the GUI
4.1.1 Viewing IPv4 Multicast Snooping Configurations
Choose the menu Multicast > Multicast Table > IPv4 Multicast Table to view all valid
Multicast IP-VLAN-Port entries
.
Figure 4-1 IPv4 Multicast Table
Search Option
Search Option Search for specific multicast entries by using Multicast IP, VLAN ID and Forward Port.
Multicast IP Table
Multicast IP Multicast source IP.
VLAN ID ID of the VLAN that the multicast group is in.
Forward Port All ports in the multicast group, including router ports and member ports.
4.1.1 Viewing IPv6 Multicast Snooping Configurations
Choose the menu Multicast > Multicast Table > IPv6 Multicast Table to view all valid
Multicast IP-VLAN-Port entries.
