![Tp-Link T1700G-28TQ V2 [633/772] Tips the logged in guests can get administrative privileges by using the command enable admin and providing the enable password](/views2/1472751/page633/bg279.png)
Configuration Guide 608
Configuring Network Security AAA Configuration
To configure the local Enable password for getting administrative privileges, follow these
steps:
Step 1 configure
Enter global configuration mode.
Step 2 enable admin password { [ 0 ]
password
| 7
encrypted-password
}
Set the Enable password. This command uses symmetric encryption.
0 and 7 represent the encryption type. 0 indicates that an unencrypted key will follow. 7
indicates that a symmetric encrypted key with a fixed length will follow. By default, the
encryption type is 0.
password
is a string from 1 to 31 alphanumeric characters or symbols.
encrypted-password
is a symmetric encrypted key with a xed length, which you can copy
from the conguration le of another switch. The key or encrypted-key you congured here
will be displayed in the encrypted form.
enable admin secret { [ 0 ]
password
| 5
encrypted-password
}
Set the Enable password. This command uses MD5 encryption.
0 and 5 are the encryption type. 0 indicates that an unencrypted key will follow. 5 indicates
that an MD5 encrypted password with fixed length will follow. By default, the encryption
type is 0.
password
is a string from 1 to 31 alphanumeric characters or symbols.
encrypted-
password
is an MD5 encrypted password with fixed length, which you can copy from
another switch’s conguration le.
Step 3 end
Return to privileged EXEC mode.
Step 4 copy running-config startup-config
Save the settings in the configuration file.
On the Server
The accounts created by the RADIUS/TACACS+ server can only view the configurations
and some network information without the Enable password.
Some configuration principles on the server are as follows:
For Login authentication configuration, more than one login account can be created on
the server. Besides, both the user name and password can be customized.
For Enable password configuration:
On RADIUS server, the user name should be set as $enable$, and the Enable
password is customizable. All the users trying to get administrative privileges
share this Enable password.
On TACACS+ server, the Enable password is set with the login account, and each
account has its own Enable password.
Tips:
The logged-in guests can get administrative privileges by using the command
enable-admin and providing the Enable password.
