Configuring Network Security 802.1X Configuration
Configuration Guide
583
Guest VLAN Select whether to enable Guest VLAN. By default, it is disabled.
If the Guest VLAN is enabled, a port can access resources in the guest VLAN even
though the port is not yet authenticated; if guest VLAN is disabled and the port is
not authenticated, the port cannot visit any resource in the LAN.
Guest VLAN ID Enter the guest VLAN's ID. It must be an existing VLAN with the ID ranging from 2
to 4094.
Accounting Enable or disable 802.1X accounting function.
2) In the Authentication Config section, enable Quiet, configure the Quiet timer, and click
Apply.
Quiet Enable or disable the Quiet timer.
Quiet Period Specify the Quiet Period. It ranges from 1 to 999 seconds and the default time is
10 seconds.
The quiet period starts after the authentication fails. During the quiet period, the
switch does not process authentication requests from the same client.
Retry Times Specify the maximum number of attempts to send the authentication packet. It
ranges from 1 to 9 times and the default is 3 times.
Supplicant
Timeout
Specify the maximum time which the switch waits for a response from the client. It
ranges from 1 to 9 seconds and the default time is 3 seconds.
If the switch does not receive any reply from the client within the specified time, it
will resend the request.
