Configuration Guide 85
Configuring Stack Stack Configuration
2.2.2 Renumbering the Stack Member
Follow these steps to renumber of the specified stack member:
Step 1 configure
Enter global configuration mode.
Step 2 switch
unit-id
renumber {
new-id
| auto-numbering}
Configure the new stack number of the specified stack member. The new number
goes into effect after this stack member resets.
unit-id:
Specify the stack member to be configured.
new-id:
Specify the member’s new stack number.
auto-numbering: The specified member will obtain its stack number through auto-
numbering.
Step 3 show switch [
unit-id
]
Displays the information of all the stack members or of the specified stack member.
Step 4 end
Return to privileged EXEC mode.
Step 5 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to renumber stack unit1 as unit4:
Switch#configure
Switch(config)#switch 1 renumber 4
Switch(config)#show switch 1
Stack Topo : Solo
Switch/Stack Mac Address : 50:C7:BF:07:5F:0E
Switch# New ID Role Mac Address Priority Version Switch Type State
------- --------- ------ ----------------- -------- ------- ---------------- -----
* 1 4 Master 50:C7:BF:07:5F:0E 15 2.0.0 T1700G-28TQRev2 Ready
Switch(config)#end
Switch#copy running-config startup-config
2.2.3 Configuring the Stack Port
Follow these steps to enable the specified port as stack port:
