Configuring Network Security ARP Inspection Configurations
Configuration Guide
573
Switch#copy running-config startup-config
4.2.3 Viewing ARP Statistics
On privileged EXEC mode or any other configuration mode, you can use the following
command to view ARP statistics:
show ip arp inspection statistics
View the ARP statistics on each port, including whether the port is trusted port and the number of received
ARP packets on the port.
