![Tp-Link T1700G-28TQ V2 [744/772] Switch config if snmp server traps link status](/views2/1472751/page744/bg2e8.png)
Configuring SNMP & RMON Notification Configurations
Configuration Guide
719
Step 2 interface {fastEthernet
port
| range fastEthernet
port-list
| gigabitEthernet
port
| range
gigabitEthernet
port-list
| ten-gigabitEthernet
port
| range ten-gigabitEthernet
port-list
]
Configure notification traps on the specified ports.
port/port-list:
The number or the list of the Ethernet ports that you desire to configure
notification traps.
Step 3 snmp-server traps link-status
Enable SNMP extended linkup and linkdown traps. By default, it is disabled.
Step 4 end
Return to privileged EXEC mode.
Step 5 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to configure the switch to enable link-status trap:
Switch#configure
Switch(config)#interface gigabitEthernet 1/0/1
Switch(config-if)#snmp-server traps link-status
Switch(config-if)#end
Switch#copy running-config startup-config
