![Tp-Link T1700G-28TQ V2 [374/772] Vlan id 3](/views2/1472751/page374/bg176.png)
Configuring Layer 2 Multicast Configuring MLD Snooping
Configuration Guide
349
Switch(config)#show ipv6 mld snooping vlan 3
Vlan Id: 3
Router Time:500
Member Time:400
Static Router Port:None
Dynamic Router Port:None
Switch(config)#end
Switch#copy running-config startup-config
Configuring Static Router Port
Step 1 configure
Enter global configuration mode.
Step 2 ipv6 mld snooping vlan-config
vlan-id-list
[rport interface {fastEthernet
port-list
|
gigabitEthernet
port-list
| ten-gigabitEthernet
port-list
| port-channel
port-channel-id
}]
port-list
and
port-channel-id
are the static router ports in the specified VLAN.
Step 3 show ipv6 mld snooping vlan
vlan-id
Show the basic MLD snooping configuration in the specified VLAN.
Step 4 end
Return to privileged EXEC mode.
Step 5 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to enable MLD Snooping in VLAN 2 and configure port
1/0/2 as the static router port:
Switch#configure
Switch(config)#ipv6 mld snooping
Switch(config)#ipv6 mld snooping vlan-config 2 rport interface gigabitEthernet 1/0/2
Switch(config)#show ipv6 mld snooping vlan 2
Vlan Id: 2
Router Time:0
Member Time:0
Static Router Port:Gi1/0/2
Dynamic Router Port:None
