Configuring DHCP Relay Overview
Configuration Guide
427
1
Overview
DHCP Relay is used to process and forward DHCP packets between different subnets.
Since the client requests a dynamic IP address via broadcast, the basic network model
of DHCP requires that the client and the server should be on the same LAN. Therefore,
each LAN should be equipped with a DHCP server, thus increasing the costs of network
construction.
DHCP Relay solves this problem. As the following figure shows, the DHCP Relay device acts
as a relay agent and forwards DHCP packets between DHCP clients and DHCP servers on
different subnets, so that DHCP clients on different subnets can share one DHCP server.
Figure 1-1 Application Scenario of DHCP Relay
DHCP Server
192.168.1.1/24
DHCP Clients
192.168.2.0/24
DHCP Clients
192.168.3.0/24
Switch
DHCP Relay
