![Tp-Link T1700G-28TQ V2 Руководство пользователя онлайн [555/772] 394694](/views2/1472751/page555/bg22b.png)
Configuration Guide 530
Configuring ACL ACL Configuration
Step 5 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to create Standard-IP ACL 600, and configure Rule 1 to
permit packets with source IP address 192.168.1.100
：
Switch#config
Switch(config)#access-list create 600
Switch(config)#rule 1 permit sip 192.168.1.100 smask 255.255.255.255
Switch(config)#show access-list 600
Standard IP access list 600
rule 1 permit sip 192.168.1.100 smask 255.255.255.255
Switch(config)#end
Switch#copy running-config startup-config
Extend-IP ACL
Step 1 configure
Enter global configuration mode.
Step 2 access-list create
access-list-num
Create an Extend-IP ACL
access-list-num
：
Enter an ACL ID. The ID ranges from 1500 to 2499.
