Configuration Guide 150
Monitoring Traffic Traffic Monitor
Sent: Displays the detailed information of sent packets.
Broadcast: Displays the number of valid broadcast packets transmitted on the
port. Error frames are not counted in.
Multicast: Displays the number of valid multicast packets transmitted on the port.
Error frames are not counted in.
Unicast: Displays the number of valid unicast packets transmitted on the port.
Error frames are not counted in.
Jumbo: Displays the number of valid jumbo packets transmitted on the port.
Error frames are not counted in.
Collisions: Displays the number of collisions experienced by a half-duplex port
during packet transmissions.
