Configuration Guide 158
Managing MAC Address Table Address Configurations
Figure 2-2 Binding Dynamic MAC Address Entries
Follow these steps to bind dynamic MAC address entries:
1) Select your desired MAC address entries. You can select the entries from the Dynamic
Address Table, or quickly search them out by MAC address/ VLAN ID/ port in the
Search Option section.
2) Click Bind, and then the selected entries will not age.
Note:
•
In the same VLAN, once an address is configured as a static address, it cannot be set as a filter-
ing address, and vice versa.
•
Multicast or broadcast addresses cannot be set as static addresses.
•
Ports in LAGs (Link Aggregation Group) are not supported for static address configuration.
