Configuration Guide 444
Configuring ARP ARP Configurations
show ip arp { gigabitEthernet
port
| port-channel
lagid
| vlan
id
}
Verify the active ARP entries associated with a Layer 3 interface.
port:
Specify the number of the routed port.
lagid:
Specify the ID of the LAG.
id:
Specify the VLAN interface ID.
