![Tp-Link T1700G-28TQ V2 Руководство пользователя онлайн [489/772] 394694](/views2/1472751/page489/bg1e9.png)
Configuration Guide 464
Configuring QoS Bandwidth Control Configuration
Step 5 end
Return to privileged EXEC mode.
Step 6 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to configure the upper rate limit of broadcast packets as
148800 pps on port 1/0/5:
Switch#configure
Switch(config)#interface gigabitEthernet 1/0/5
Switch(config-if)#storm-control pps
Switch(config-if)#storm-control broadcast pps 148800
Switch(config-if)#show storm-control interface gigabitEthernet 1/0/5
Port BcRate Mcate UlRate LAG
--------- ---------------- -------------- -------------- -------------
Gi1/0/5 pps 148800 pps 0 pps 0 N/A
Switch(config-if)#end
Switch#copy running-config startup-config
The following example shows how to configure the upper rate limit of broadcast packets as
10240 kbps on port 1/0/5:
Switch#configure
Switch(config)#interface gigabitEthernet 1/0/5
Switch(config-if)#no storm-control pps
Switch(config-if)#storm-control broadcast kbps 10240
Switch(config-if)#show storm-control interface gigabitEthernet 1/0/5
Port BcRate Mcate UlRate LAG
--------- ---------------- -------------- -------------- -------------
Gi1/0/5 kbps 10240 kbps 0 kbps 0 N/A
Switch(config-if)#end
Switch#copy running-config startup-config
