Configuration Guide 216
Configuring Protocol VLAN Configuration Example
Figure 3-4 Create VLAN 10
2) Click Create to load the following page. Create VLAN 20, and add port 1/0/1 as tagged
port and port 1/0/3 as untagged port to VLAN 20. Click Apply.
