English | 27
2 610 A15 294 • 7.5.12
6 Charge-control indicator
7 Shock-warning indicator
8 Shock-warning button
9 Lower direction button
10 Upper direction button
11 Indicator for single-axis slope operation
12 Button for single-axis slope operation
13 Exit opening for laser beam
14 Variable laser beam
15 Plumb beam (RL25HV)
16 Battery compartment
17 Socket for charge connector*
18 Battery pack*
19 Nut for battery compartment/battery pack
20 Tripod mount 5/8"
21 Serial number
22 Laser warning label
23 Laser receiver
24 Construction laser measuring rod*
25 Tripod*
26 Remote control*
27 Laser viewing glasses*
28 Wall mount/alignment unit*
29 Laser target plate*
30 Case
31 Battery charger
32 Charge connector
* The accessories illustrated or described are not included as stand-
ard delivery.
Technical Data
Assembly
Power Supply
The measuring tool can be used either with commercially availa-
ble batteries/rechargeable batteries, which are inserted in bat-
tery compartment 16, or with the CST/berger battery pack 18.
Operation with Batteries/Rechargeable Batteries
Using alkali-manganese or rechargeable batteries is recom-
mended for operation of the measuring tool.
To insert the batteries/rechargeable batteries, loosen nut 19
and remove the battery compartment 16.
Rotational Laser Level RL25H RL25HV
Article number F 034 K61 0NE F 034 K61 0N5
Working range (radius)
– without laser receiver, approx.
– with laser receiver, approx.
30 m
225 m
30 m
225 m
Levelling Accuracy
1) 2)
± 0.08 mm/m ± 0.08 mm/m
Self-levelling range, typically ±8% (±5°) ±8% (± 5°)
Levelling duration, typically 15 s 15 s
Rotational speed 600 min
-1
150/300/600 min
-1
Aperture angle for line operation – 10/25/50°
Operating temperature –10...+50 °C –10...+50 °C
Storage temperature –20...+70 °C –20...+70 °C
Relative air humidity, max. 90 % 90 %
Laser class 22
Laser type 635 nm, <1 mW 635 nm, <1 mW
Laser beam Ø at the exit opening, approx.
1)
5mm 5mm
Tripod mount (horizontal) 5/8"-11 5/8"-11
Batteries (NiMH)
Batteries (alkali-manganese)
2 x 1.2 V HR20 (D) (9 Ah)
3x1.5VLR20 (D)
2x1.2VHR20 (D) (9Ah)
3 x 1.5 V LR20 (D)
Operating life time, approx.
3)
– Batteries (NiMH)
– Batteries (alkali-manganese)
30 h
85 h
30 h
55 h
Weight according to EPTA-Procedure 01/2003 2.3 kg 2.3 kg
Dimensions (length x width x height) 200 x 220 x 190 mm 200 x 220 x 190 mm
Degree of protection IP 56 (protected against dust
and powerful water jets)
IP 56 (protected against dust
and powerful water jets)
1) at 20 °C
2) alongside the axes
3) The operating duration depends on the characteristics of the batteries/rechargeable batteries being used and can vary with different manufacturers.
The measuring tool can be clearly identified with the serial number 21 on the type plate.
