Remote Control
Safety Notes
Read and observe all instructions. SAVE
THESE INSTRUCTIONS FOR FUTURE REFER-
ENCE.
f Have the remote control repaired only through a quali-
fied repair person and only using identical replacement
parts. This will ensure that the functionality of the remote
control is maintained.
f Do not operate the remote control in explosive atmos-
pheres, such as in the presence of flammable liquids,
gases or dusts. Sparks can be created in the remote control
which may ignite the dust or fumes.
f Read and strictly observe the safety warnings in the op-
erating instructions of the rotational laser.
Product Description and Specifications
Intended Use
The remote control is intended for controlling CST/berger rota-
tional laser levels with infra-red receivers, in indoor and outdoor
use.
Product Features
The numbering of the product features refers to the illustration
of the remote control on the graphics page (see page 8).
53 Standby button
54 Operation indicator
55 Button for line operation and line length selection
56 Right direction button
57 Button for “rotation in clockwise direction”
58 Lower direction button
59 Button for “rotation in anticlockwise direction”
60 Left direction button
61 Button for rotational operation and selection of the
rotation speed
62 Button for single-axis slope operation
63 Upper direction button
64 Serial number
65 Battery lid
66 Latch of battery lid
67 Outlet opening for infra-red beam
The accessories illustrated or described are not included as standard
delivery.
Technical Data
Assembly
Inserting/Replacing the Battery
Using alkali-manganese batteries is recommended for opera-
tion of the remote control.
To open the battery lid 65, press on the latch 66 and remove the
battery lid. Insert the batteries. When inserting, pay attention to
the correct polarity according to the representation on the in-
side of the battery compartment.
The batteries must be replaced when operation indicator 54 no
longer lights up after pressing any button on the remote control.
Always replace all batteries at the same time. Only use batteries
from one brand and with the identical capacity.
f Remove the batteries from the remote control when not
using it for longer periods. When storing for longer peri-
ods, the batteries can corrode and discharge themselves.
Operation
Initial Operation
f Protect the remote control against moisture and direct
sunlight.
f Do not subject the remote control to extreme tempera-
tures or variations in temperature. As an example, do not
leave it in vehicles for longer periods. In case of large varia-
tions in temperature, allow the remote control to adjust to
the ambient temperature before putting it into operation.
The remote control remains ready for operation as long as bat-
teries with sufficient voltage are inserted.
Set up the rotational laser in such a manner that the signals of
the remote control directly reach one of the reception lenses on
the rotational laser (for this, see the operating instructions of
the rotational laser). When the remote control cannot be point-
ed directly against a receiption lens, the working range is re-
duced. By reflecting the signal (e.g. against walls), the working
range can be improved, even for indirect signals.
After pressing a button on the remote control, the illuminated
operation indicator 54 indicates that a signal was sent out.
Switching the rotational laser on/off with the remote control is
not possible.
Remote Control RM7
Article number F 034 K69 0N1
Working range
1)
30 m
Operating temperature –10 °C ... +50 °C
Storage temperature –20 °C...+70 °C
Batteries 2 x 1.5 V LR06 (AA)
Weight according to
EPTA-Procedure 01/2003
0.11 kg
1) The working range can be decreased by unfavourable environmental
conditions (e.g. direct sun irradiation).
For clear identification of your remote control, see the serial number 64 on
the type plate.
