ENGINE RIGHT SIDE 5-3
Exploded View
Torque
No. Fastener N·m kgf·m ft·lb Remarks
1 Right Engine Cover Bolts 8.8 0.9 78 in·lb
2 Clutch Spring Bolts 12 1.2 104 in·lb
3 Primary Clutch Hub Nut 127 13 94 MO
4
Secondary Clutch Hub Nut
78 8.0 58
MO
5 Balancer Drive Gear Nut 83 8.5 61 MO
6 Balancer Gear Nut 118 12 87 MO
7 Clutch Adjusting Screw Locknut 11 1.1 95 in·lb
G: Apply grease for oil seal and O-ring.
MO: Apply molybdenum disulfide oil.
O: Apply engine oil.
