1-8 GENERAL INFORMATION
General Specifications
Item KLF250-A1 ∼ A3
Brake type:
Front Drum (Mechanical)
Rear Drum (Mechanical)
Electrical Equipment
Battery 12 V 14 Ah, (US) 12 V 11 Ah
Headlight:
Type Semi-sealed beam
Bulb 12 V 25/25 W × 2
Tail/brake light 12 V 8/27 W × 2
Alternator:
Type Three - phase AC
Rated Output 13 A, 14 V @8 000 r/min (rpm)
Specifications are subject to change without notice, and may not apply to every country.
(CA): Canada Model
(US): U.S.A. Model
