12-6 BRAKES
Brake Adjustment
•
Mount the cam lever at a new position so that the cam
lever has the proper angle when the brake is fully applied.
Cam Lever Angle (front and rear)
Standard: 80 ∼ 90°
WARNING
When remounting the cam, be sure that the position
of the indicator on the serrated shaft is not altered.
A change in cam lever angle is caused by wear of
internal brake parts. Whenever the cam lever angle
is adjusted, also check for drag and proper opera-
tion, taking particular note of the brake lining wear
indicator position.
In case of doubt as to braking effectiveness, disas-
semble and inspect all internal brake parts. Worn
parts could cause the brake to lock or fail.
