PERIODIC MAINTENANCE 2-5
Torque and Locking Agent
Torque
Fastener
N·m kgf·m ft·lb
Remarks
Final Gear Case Drain Bolt 20 2.0 14
Speedometer Plug 20 2.0 14
Final Gear Case Filler Cap 15 1.5 11
Ring Gear Cover Bolts
25 2.5 18 L
Axle Shaft Pipe Bolts 20 2.0 14
Oil Level Inspection Bolt 7.8 0.8 69 in·lb
Brakes
Front Axle Nut 34 3.5 25
Rear Axle Nut 147 15 108
Front Brake Panel Bolts 25 2.5 18 L
Rear Brake Panel Bolts 29 3.0 22 L
Rear Brake Drum Drain Bolts 29 3.0 22
Suspension
Front Suspension Arm Pivot Bolts 88 9.0 65
Rear Suspension Arm Pivot Bolts and Nuts 34 3.5 25
Shock Absorber Mounting Bolts and Nuts
34 3.5 25
Steering Knuckle Pivot Nuts 39 4.0 29
Steering
Steering Stem Clamp Allen Bolts 26 2.7 20
Stem Bottom End Nut 29 3.0 22
Tie-rod End Nuts 41 4.2 30
Tie-rod Adjusting Sleeve Locknuts 26 2.7 20
Steering Knuckle Arm Pivot Nuts 39 4.0 29
Handlebar Holder Bolts 20 2.0 14 S
Frame
Rear Carrier Bolts 20 2.0 14
Electrical System
Alternator Cover Bolts
8.8 0.9 78 in·lb
Spark Plug 14 1.4 10
Starter Motor Clutch Bolts 34 3.5 25 L
Ignition Switch Nut 2.9 0.3 26 in·lb
Alternator Rotor Bolt 59 6.0 43
Starter M otor Mounting Bolts 8.8 0.9 78 in·lb
Starter Motor Terminal Nut 4.9 0.5 43 in·lb
Starter Motor Terminal Locknut 6.9 0.7 61 in·lb
Starter Motor Bolts 3.4 0.3 30 in·lb
