11-6 FINAL DRIVE
Specifications
Item Standard
Bevel Gear Backlash
Front 0.06 ∼ 0.13 mm (0.024 ∼ 0.0051 in.) (at driven gear shaft nut)
Final 0.13 ∼ 0.25 mm (0.0051 ∼ 0.0098 in.) (at ring gear tooth)
Final Gear Case Oil
Type
API GL-5 Hypoid gear oil
Viscosity SAE90 (above 5°C, 41°F)
SAE80 (below 5°C, 41°F)
Capacity 0.2 L (0.21 US qt)
