CRANKSHAFT/TRANSMISSION 9-3
Exploded View
Torque
No. Fastener N·m kgf·m ft·lb Remarks
1 Engine Drain Plug 29 3.0 22
2 Crankcase Bolts 8.8 0.9 78 in·lb
3 Clutch Release Cam Pin 25 2.5 18 L
4 Return Spring Pin 25 2.5 18 L
5 Output Shaft Bearing Position Plate Screws 8.8 0.9 78 in·lb L
6 Relief Valve 15 1.5 11 L
7
Bearing Stopper Screws
9.8 1.0 87 in·lb
L: Apply a non-permanent locking agent.
LG: Apply liquid gasket (Kawasaki Bond: 92104–002).
MO: Apply molybdenum disulfide oil.
O: Apply engine oil.
