FINAL DRIVE 11-5
Exploded View
Torque
No. Fastener N·m kgf·m ft·lb Remarks
1 Final Gear Case Drain Bolt 20 2.0 14
2 Speedometer Plug 20 2.0 14
3 Final Gear Case Filler Cap 15 1.5 11
4
Ring Gear Cover Bolts
25 2.5 18 L
5 Axle Shaft Pipe Bolts 20 2.0 14
6 Oil Level Inspection Bolt 7.8 0.8 69 in·lb
7: Australia and Europe Models
8: U.S.A., Canada and United Kingdom Models
LG: Apply liquid gasket (Three Bond 1215, Gray)
L: Apply a non-permanent locking agent.
M: Apply molybdenum disulfide grease.
