LIST OF ABBREVIATIONS
A
ampere(s)
lb
pounds(s)
ABDC after bottom dead center
m
meter(s)
AC
alternating current min
minute(s)
ATDC after top dead center
N
newton(s)
BBDC before bottom dead center
Pa
pascal(s)
BDC
bottom dead center
PS
horsepower
BTDC before top dead center
psi
pound(s) per square inch
°C degree(s) Celcius
r revolution
DC
direct current rpm
revolution(s) per minute
F
farad(s) TDC
top dead center
°F degree(s) Fahrenheit
TIR total indicator reading
ft foot, feet
V
volt(s)
g
gram(s)
W
watt(s)
h
hour(s) Ω ohm(s)
L
liter(s)
Read OWNER’S MANUAL before operating.
