ENGINE TOP END 4-5
Exploded View
Torque
No. Fastener N·m
kgf·m ft·lb
Remarks
1
Camshaft Sprocket Bolt
34 3.5 25
MO
2
Rear Camshaft Chain Guide Bolt
9.8 1.0 87 in·lb
3
Camshaft Chain Tensioner Mounting Bolts
8.8 0.9 78 in·lb
4
Valve Adjusting Screw Locknuts
12 1.2 104 in·lb
5
Rocker Shaft Retainer Screws
4.4 0.45 39 in·lb
6
Camshaft Chain Guard Screws
4.4 0.45 39 in·lb
M: Apply molybdenum disulfide grease.
MO: Apply molybdenum disulfide oil.
R: Replacement Parts
