Kawasaki WORKHORSE 250 (2003) [16/322] 6 general information
![Kawasaki WORKHORSE 250 (2003) [16/322] 6 general information](/views2/1121215/page16/bg10.png)
1-6 GENERAL INFORMATION
General Specifications
Item KLF250-A1 ∼ A3
Dimensions
Overall Length 1 780 mm (70.08 in..)
Overall Width 1 120 mm (44.09 in.),
(US) (CA) 1 020 mm (40.16 in.)
Overall Height 1 040 mm (40.94 in.)
Wheelbase 1 115 mm (43.90 in.)
Ground Clearance 155 mm (6.10 in.)
Seat Height 730 mm (28.74 in.)
Dry Mass 185 kg (408 lb), (US) 183 kg (404 lb),
(CA) 183.5 k g (405 lb)
Curb Mass:
Front
89 kg (196 lb), (US) (CA) 88.5 (195 lb)
Rear 106 kg (234 lb), (US) 104.5 kg (230 lb),
(CA) 105 kg (232 lb)
Fuel Tank Capacity 10 L (2.6 US gal)
Performance
Minimum Turning Radius 2.7 m (8.86 ft)
Engine
Type 4-stroke, SOHC, 1-cylinder
Cooling System Air-cooled
Bore and Stroke 69.0 × 61.0 mm ( 2.72 × 2.40 in.)
Displacement 228 mL (13.9 cu in.)
Compression Ratio 8.9
Maximum Horsepower 12.5 kW (17 PS) @7 000 r/min (rpm), (US) –
Maximum Torque 17.9 N·m (1.83 kgf·m, 13.24 ft·lb)
@5 500 r/min (rpm)
Carburetion System Carburetor, MIKUNI VM24SS
Starting System Electric starter & Recoil starter
Ignition System CDI
Timing Advance Electronically advanced
Ignition Timing From 10° BTDC @1 800 r/min (rpm)
to 35° BTDC @4 600 r/min (rpm)
Spark Plug NGK DR8ES
Valve Timing:
Inlet: Open 35° BTDC
Close 57° ABDC
Duration 272°
Exhaust: Open 54° BBDC
Close 26° ATDC
Duration 260°
Lubrication System Forced lubrication (wet sump)
Engine Oil: Type API SF or SG
API SH or SJ with JASO MA
Viscosity SAE 10W-40
Capacity 2.0L(2.11USqt)
