RECOIL STARTER 6-3
Exploded View
Torque
No. Fastener N·m kgf·m ft·lb Remarks
1 Recoil Starter Mounting Bolts 8.8 0.9 78 in·lb
2 Recoil Starter Flange Nut 12 1.2 104 in·lb
Gr: Apply grease.
